Trundles Heavy Duty Green Tow Point (Pair) to suit Ford Ranger PX1/2/3 & Mazda BT-50 Series II 2011-2022

Important notes can be found in the IMPORTANT tab! Please read thoroughly before making your order.

A must have for anyone considering any type of off road or remote touring. The factory tow points are no better than a tie down point for transport. These Recovery points will allow you to use a Bridle strap to ensure an even tow.

• Made from 10mm Plate Steel
• Using SS41 carbon steel plate (Q235)
• Direct bolt on to your chassis
• No cutting or welding required
• Sold as a pair
• Option of using a Bridle strap
• Powdercoated Green for High visibility
• Destruction tested to over 100.4kN (10.23 ton force) EACH
• Each component will be rated to a WLL (Working Load Limit) of 3250kgs
• Only to be used with a shackle rated to maximum 3.25t.

COMPONENTS

1x Heavy Duty Tow Point Kit - RP-RAN02

SUITS

ARB, ARB Summit Bar, ECB, Opposite Lock, Ironman, XROX, MCC, Genuine Bullbar, Factory Bumper, Factory Nudge Bar, Shoreline, Others

IMPORTANT!

• Vehicles manufactured post 06/2018 have a stiffening rib in the front section of the chassis rail which affects fitment. Please refer to the fitting guide for modification of fitment.
• Factory bumper: modify lower plastic bumper for point to clear.
• MCC: RP-RAN02 can fit with modification, requires hole drilled to accept mounting bolt on passenger side (will be included in V2) Trimming of bar side plates required, when tow point fitted there will be no strength lost at this mount. You can completely remove the driver side mount - these are included in the bar manufacture for LHD vehicles.
• Ironman: RP-RAN02 can fit with modification, requires hole drilled to accept mounting bolt on passenger side (will be included in V2) Trimming of bar side plates required, when tow point fitted there will be no strength lost at this mount. You can completely remove the driver side mount - these are included...
