THIS HOIST CAN BE SUPPLIED WITH A REMOTE CONTROL - CONTACT US TO DISCUSS YOUR NEEDS

FEATURES

> Full current and shunt limit switches operate in both directions of hook travel. > Overload Limiter: this electro-mechanical device is exclusive to the Hitachi range and boasts a far more superior overload protection device than the slipping clutch method. > Braking: all models are fitted with an electro-magnetic, self-adjusting disc type brake to the gearbox and the “F” models have an additional auxiliary centrifugal brake fitted to the motor > Chain Bucket: noiseless design with flexible mounting > High quality Grade 80 zinc or nickel plated load chain supplied as standard. > IP54 protection rating on all electric hoists and trolleys. > Motor thermal protection on all Hitachi models. > Optional radio remote control with 1 or 2 transmitters. > Ambient temperature requirement of -10 to 40 degrees. > Class M4 inclusive of 180 starts per hour. > Completely enclosed design. Entire mechanism including; the motor, dual brake system, gears, rotating parts and electrical system can be operated under severe conditions.

SPECIFICATIONS

> Rated Capacity 2 ton > Lift Height 6m > Speed m/min 6.8/1.7 > Motor 2.4/0.6kw 3 phase > Weight 96kg > Headroom 660mm > Duty Cycle 30%

Please contact us if you require a greater lift height, hoists can be modified to meet your criteria. There is a 1 week lead time for hoists sold with remote control or custom chain lengths.
