Low Voltage Detection Battery protection Controller, Adjustable with display

Features: Adjustable hysteresis UPPER and LOWER set points 3 digit LED display RED showing the upper and lower set voltages, and normal run voltage, with adjustable 0-9 min display OFF timer d (0 is always on default) Adjustable delay timer dL 0-9 sec, to prevent erratic operation 20A relay output. Adjustable offset voltage correction (+/- 0.5V for calibration) With power reverse protection, over-voltage and short-circuit protection. Output state indicator LED (green) NON volatile settings memory Input Voltage Range 9-20 V dc (Over 20V display shows “HHH” DIN rail mountable as well as screw fix Removable header connector

Specifications: Input Voltage: DC 9-20V Max. Load: 16V 20A Relay Close Current: 50 mA Quiescent Current: 4.3 mA Operating Temperature: -40 deg c to +85 deg c Dimension: 65 x 46 x 29 mm Weight: 47g

Package List: 1 x Voltage Control Relay
