STARTECH GIGABIT ETHERNET CARD 10 100 1000BASE T PLUG IN CARD PCI EXPRESS

Add a 10/100/1000Mbps Ethernet port to any PC through a PCI Express slot. The ST1000SPEX2 PCIe Gigabit Ethernet Network Card adds a 10/100/1000 Mbps compatible RJ45 Ethernet port to a PCI Express-enabled client, server or workstation, providing a convenient addition or replacement networking interface.

Compliant with IEEE 802.3/u/ab standards, and with support for 9K Jumbo Frames, VLAN tagging and Wake on LAN (WOL), this versatile Gigabit NIC/Server Adapter delivers rock-solid performance.

Plus, the card includes both full profile and low profile/half-height installation brackets for installation in a wide range of computer/server chassis, regardless of form factor.

SPECIFICATIONS

Media & Performance

Data Transfer Rate: 128 MB/s

Media Type Supported: Twisted Pair

Network & Communication

Network Technology: 10/100/1000Base-T

InfiniBand: No

General Information

Product Type: Gigabit Ethernet Card

Manufacturer Part Number: ST1000SPEX2

Manufacturer: StarTech.com

Product Name: 1 Port PCI Express PCIe Gigabit Network Server Adapter NIC Card - Dual Profile

Brand Name: StarTech.com

Device Supported: PC

Platform Supported: PC

Mac

System Requirements: Windows 10

Environmentally Friendly: Yes

Environmental Certification: RoHS

Physical Characteristics

Thickness: 20 mm

Weight (Approximate): 36 g

Form Factor: Plug-in Card

Height: 80 mm

Width: 120 mm

Card Height: Low-profile

Full-height

Interfaces/Ports

Host Interface: PCI Express x1

USB: No

Number of Network (RJ-45) Ports: 1

Network (RJ-45): Yes

Serial Port: No

Total Number of Ports: 1

Ethernet AUI: No

XJACK: No

PoE (RJ-45) Port: No

PACKAGE CONTENTS

1 x 1 Port PCI Express PCIe Gigabit Network Server Adapter NIC Card - Dual Profile

1 x Low Profile Bracket

1 x Driver CD

1 x Instruc...
