Superb 70's Japanese masterpiece that's up with the finest vintage Integrateds available today. If you're wanting a centrepiece capable of switching between 2 turntables with cartridge loading + various other sources, this is for you. Working as it should with all controls operating smoothly, the sound quality is as good as you could hope for.

JVC 4VN-880 Integrated 2/4 Channel Quadrophonic Amplifier

The 4VN-880 integrated amplifier features a 3 stage direct coupled equaliser circuit and NF type tone control.

The use of BTL connection enables the amplifier to double its power when it is used as a 2-channel amplifier.

In the first stage of the main amplifier there is a phase reversing circuit which reverses the phases of the input signals.

The original input signals go to the CH-1 and CH-3 amplifiers and the reversed phase signals go to the CH-2 and CH-4 amplifiers.

At output the signals are composed giving an output theoretically 4 times greater than in 4-channel playback.

Specifications Power output: 55W/ch into 8 ohms (stereo), 25W/ch into 8 ohms (quadraphonic)

Frequency response: 20Hz to 50kHz

Total harmonic distortion: 0.5%

Damping factor: 50

Input sensitivity: 2mV (MM), 100mV (line)

Signal to noise ratio: 65dB (MM), 75dB (line)

Output: 100mV (line), 30mV (DIN)

Speaker load impedance: 4 - 16 ohms

Dimensions: 138 x 420 x 362mm

Weight: 12kg
