SMSL M500 DAC and Headphone Amplifier All-in-one DAC/amp Optimized for high-end audio User-friendly operation ESS ES9038PRO DAC XMOS XU-208 USB chipset Dual OPA1612 op amps delivers articulated sound into any pair of headphones/ monitors 2.19-inch LG TFT LCD display Wide range of inputs & outputs XLR output & RCA outputs Dual optical inputs & coaxial input Preamp unit with independent headphone

SMSL ESS ES9038PRO DAC XMOS XU-208 USB chipset (2) OPA1612 op amps 2.19 in LG TFT LCD display Inputs - (1) USB, (1) Coaxial, (2) Optical Outputs - (1) RCA headphone amplifier, (1) RCA, (1) XLR THD+N - 0.00015% XLR dynamic range: 125dB RCA dynamic range - 120dB SNR dynamic range - 120dB USB transmission - Asynchronization USB compatibility - Windows 7 / 8 / 8.1 / 10, Mac OSX10.6 or later, Linux USB bit depth: 1-bit, 16 / 32-bit Optical / Coaxial bit depth - 1-bit, 16 / 32-bit USB sampling rate - PCM 44.1 / 768kHz DSD sampling rate - 2.8224 / 22.5792MHz, DSD64 (DoP) Optical / Coaxial sampling rate - PCM 44.1 / 192kHz Headphone amplifier output power - 570mW at 32O ohms, 290mW at 64ohms, 125mW at 150 ohms, 65mW at 300 ohms Power Consumption - 5W Standby power - <0.5W Dimensions - 3.4 x 3.5 x 7.8 in (8.5 x 8.8 x 19.7 cm) Weight - 2 lbs (0.9 kg)
