Type Integrated Amplifier with remote control Bias Automatic Power 10W - Class A Input type 5 lines, 1 Bypass output, 2 loudspeakers outputS (for bi-wiring) Bandwidth 20 Hz to 55kHz Sensibility 100 mV Number of blocks 1 Tubes list 4 x 300B, 2 x 6SN7, 3 x ECC82 Dimensions 40 X 40 X 25.5 CM Weight 40Kg Consumption 200 VA

== Jadis tube amps are hand made to order, standard lead time 12-16 weeks ==

In the world of audiophiles, there is purist group militating for simplicity in tube amplification systems focusing on the use of the tube designed in the early days of tube technology: the directly heated triodes of which the most famous is the 300B.

I300 is built around a simple 300B push-pull without feedback which offers unequalled musiciality of this tube.

After the preamplification using an ECC82, the signal feeds a phase inverter (called Schmitt) followed by 6SN7 triodes sufficient to drive the 300B.

The power supply is another strong point. In addition to the fact that each stage has its own power supply, particular care has been taken with the 300Bs themselves.

As direct heated triodes, the heater is the cathode. This requires a very "clean" power supply with no less than seven separate power circuits.

As for all our devices, transformers are designed and manufactured in our workshop. The one dedicated to the power supply, uses a magnetic circuit EI M6X of a design which gives a very stable operation, without noise and with a reduced overheating.

The output ones use a double CV38 magnetic circuit built according to our standards. The I300 is the only integrated with such an output transformer.

A design mode that allows the device to appear much more powerful than its 10W may suggest!

Listening to the I300, it’s all about accuracy, subtlety and musicality of the 300B which magnify your tracks. No doubt it will delight demanding audiophiles triode lover!
