The M3scd has been designed to give outstanding CD reproduction and to be a digital hub.

In addition to CD it has 3 digital inputs: coax, optical and asynchronous USB. This makes it particularly useful for set top boxes and/or TV sound improvement. The technical performance is excellent; it has very low distortion, extremely low jitter, excellent signal-to-noise ratio, extremely flat frequency response, exemplary linearity and excellent channel separation.

All in all the M3scd gives excellent CD replay and can act as a versatile digital hub at the same time.

M3scd - Specifications Performance

Jitter: <135 picoseconds peak to peak Frequency Response: 10Hz to 20 kHz -0.2dB max. Signal to Noise Ratio: >117dB THD(+ noise): <0.003% 10Hz to 20 kHz Linearity: <0.1dB down to -96dB Channel Separation: 105dB 20 Hz to 20 kHz

Hardware

DAC:24 bit Delta-Sigma (bit stream) dual differential 8x over-sampling

Outputs

1x line level RCA 1x RCA coaxial connector (Digital SPDIF) 1x Toslink optical connector (Digital SPDIF) 1x Trigger output - 3.5mm (1/8”) mono jack +12V DC

Inputs

1x RCA coaxial connector SPDIF 32-192 kbps (16-24 bit stereo PCM) 1x TOSLINK optical connector 32-96 kbps (16-24 bit stereo PCM) 1x USB type ‘B’ connector - Asynchronous data stream at up to 24-bit/96kHz Trigger in

General

Dimensions - WxHxD (mm): 440 x 100 x 380 Weight (unpacked / packed): 6.05 kg / 9.9 kg

Review: https://www.musicalfidelity.com/uploads/reviews/hi-fi_choice_3scd-3si.pdf https://www.musicalfidelity.com/uploads/reviews/MF_M3sCD_Stereoplay_0315-EN.pdf https://www.musicalfidelity.com/uploads/reviews/MF_M3sCD_AudioTest_042018_EN.pdf

ICOM is Musical Fidelity official retailer in NZ, entire Musical Fidelity range can be demo in our Hi-End showroom by appointment. This unit is BRAND NEW, in a sealed box, includes a full 3 year NZ warranty. Free shipping within NZ.
