ZYCAST SINGLE INPUT HD MODULATOR

We have been testing the new Q4K-R1 for months now, while the Q4K-R1 is not the first 4K modulator on the market, it's the first stable 4K modulator. Like the HD1603, the Q4K-R1 supports Resi-Linx IR targets and emitters. Resi-Linx is the market leader in both IR and modulation and the only brand to have Foxtel-approved products in both fields.

This unit has a full menu via LCD display, improved MER resulting in a good quality picture, and is configurable for New Zealand. Q4K-R1 allows you to distribute any HD source around your home/business installation over coax cable and control with ease.

FEATURES

Most cost-effective fully featured 4K HD modulator on the market

Single input digital modulator encoding HD video and stereo audio signals to MPEG-4 only(H.264) DVB-T COFDM TV channels

Compatible input resolutions 576i/720P/1080i& 1080P/UHD/4K for high definition picture quality (ensure TV tuner is MPEG4/H.264 and 4K HDCP2.2 compatible)

HDMI input with HDMI loop-through for local connectivity

IR return path- compatible with resin-Linx RL-RF380(video hub) and Rl-RF210(IR target)

Superior error rate (MER 39)

Full function front LCD display with menu-driven configuration

New Zealand channel plan selectable

2K/8K carriers

Adjustment of settings available via WEB GUI

Remote management with a PC

Adjustable VHF/UHF output (6-69)

85dB launch with adjustable attenuation

Compact design

Silent operation-No Fan Noise

SPECIFICATIONS

Video

Resolution: 1080p / 1080i / 720p

Video Codecs: H.264

Audio

Audio Codecs: MPEG1 Layer II MPEG4 AAC

Local Monitoring: LCD

IR Emitter: Single

Web GUI Supported: Firefox, Chrome, Safari

Password Protected: GUI: User Settable

Power Supply: 12VDC 1.5A

Consumption: 6.5 Watts

Operation Temperature: 0c to +45c

Storage Temperature: -20c to +70c

Dimension: 236mm...
