Description
Class D Amplifier - 1U - 2 x 360W RMS
Super compact and lightweight stereo power amplifiers in a 1U rack-mountable housing. Fully digital architecture provides high power output and efficiency with inbuilt protection circuitry. Signal inputs are balanced combo jack/XLR connectors and speaker outputs are provided as locking SPK or 4mm binding posts. Easy portability makes these amplifiers well-suited for mobile sound systems without compromising quality of the audio output.
Cutting edge class D architecture Compact and lightweight Fan cooling and internal protection circuitry Power supply230Vac, 50Hz (IEC) Input connectionsCombo jack/XLR balanced (L+R) Output connectionsSPK (L+R) + 4mm binding posts (L+R) Frequency response20Hz - 20kHz (±0.5dB) THD +N<0.05% Damping factor300 S/N ratio (A weighted) : line100dB Slew rate20V/us Input impedance10k Ohms unbalanced, 20k Ohms balanced Output circuit architectureClass D ProtectionTemperature, short circuit, DC, overload IndicatorsPower, signal, clip ControlsL+R level, power on/off, bridge/parallel/stereo, ground lift Dimensions482 x 180 x 44mm Fuse T5AL (230V) / T10AL (115V) Output power : 4 Ohms 2 x 360Wrms Output power : 8 Ohms 2 x 200Wrms Output power : bridged @ 8 Ohms 720Wrms Weight 2.6kg
We have two stores in Auckland and welcome pickups
To find us click the view store link at the bottom of the listing
https://www.trademe.co.nz/stores/sound-division/contact-us
Albany, North Shore Henderson, West Auckland
Why buy from us:
- All stock in NZ ready to ship
- 33 years in business
- Best shipping costs (no inflated rates to hide the real cost)
- Very fast delivery
- We are sound and light experts with 2 retail locations where we welcome pick ups
- We are a GST registered business and offer a warranty & GST receipt with every sale.
