RAP-365-224-1U RAM(R) Twist-Lock(TM) Triple Suction Cup Ball Base

Features

• RAM(R) Twist-Lock(TM) triple suction cup base is ideal for windshields and other nonporous surfaces
• Included round base with C size 1.5" RAM(R) rubber ball allows for connection to any C size RAM(R) double socket arm
• RAM ball and socket technology allows for near-infinite adjustability
• Made of powder-coated, marine-grade aluminum and high-strength composite for durability and reliability in the most demanding environments
• Backed by a lifetime warranty

This suction mount is ideal for high vibration environments (e.g. helicopters) and consists of a triple 83.8mm (3.3") twist lock suction cup base with plate that contains the universal AMPs hole pattern. The suction cup is designed to have an extra strong hold on any smooth non-porous surface, but for best result, mount the suction cup on a glass or non-porous plastic surface.

Includes 1.5" (C Series) round ball base

Suction Size (3) x 84mm / 3.3" Diameter Bases, Total Width 201.9mm / 7.95"

Weight Capacity Standard Use: 1.814kg (4 lbs) Heavy-Duty Use: 1.36kg (3 lbs)

Material: High Strength Composite Powder Coated Marine Grade Aluminium

Images show attached options - RAM-202U Round Base, RAM-201U (double socket arm)

Components: RAP-365-224-1BU RAM Triple Suction Cup Base with AMPs Hole Pattern RAM-202U RAM 2.5" / 63mm DIA. BASE 1.5" Ball

Q&A

What surfaces is this suction cup compatible with?

Suction cups work by creating a vacuum, so they require an extremely smooth surface. If the surface is textured at all air can get in and the suction cup with loose grip. Suction cup mounts work best against windows and highly polished metal surfaces.

Can you adjust the suction cups of this base like you can the RAM-B-189B-PIV1U?

Unfortunately no, only select dual suction cup mounts have the pivoting connection that allows the suction cups to be adjusted to a surface that isn't completely level.
