AUDIO SECTION

• Minimum RMS Output Power for Front, Center, Surround, Surround back 20 Hz to 20 kHz, 0.06% THD, 8 ? ...................................... 95 W
• Maximum Power (EIAJ)
• Dynamic Power (IHF) 8/6/4/2 ? ....................................................... 130/165/195/240 W
• Frequency Response CD terminal to Front L/R ...................... 10 Hz to 100 kHz, –3 dB
• Total Harmonic Distortion CD, etc. to Front L/R (20 Hz to 20 kHz, 50 W, 8 ?) .......... 0.06%
• Signal to Noise Ratio (IHF-A Network) CD (250 mV) to Front L/R, Effect Off .............................. 100 dB
• Residual Noise (IHF-A Network) Front L/R ................................................................ 150 µV or less
• Channel Separation (1 kHz/10 kHz) CD (5.1 k? terminated) to Front L/R ....................... 60 dB/45 dB
• Tone Control (Front L/R) BASS Boost/Cut ........................................................ ±6 dB/50 Hz BASS Turnover Frequency ................................................ 350 Hz TREBLE Boost/Cut ................................................ ±6 dB/20 kHz TREBLE Turnover Frequency .......................................... 3.5 kHz
• Phones Output .......................................................... 150 mV/100 ?
• Input Sensitivity/Input Impedance CD, etc. ................................................................. 200 mV/47 k? MULTI CH INPUT ............................................... 200 mV/47 k?
• Output Level/Output Impedance REC OUT ............................................................. 200 mV/1.2 k? PRE OUT .................................................................... 2 V/1.2 k? SUB WOOFER ........................................................... 4 V/1.7 k?

30 day warranty on electronics only (not speakers) (Return to base Repair Replace Refund) Apart from power cords If item isn't in the pictures it most likely isn't part of the auction if unsure just ask.
