SPECIFICATION

Payload 150g/0.33lb--4600g/10.14lb(lens and other accessories are included, and center of gravity of gimbal is balanced )

Battery: 18650 rechargeable battery*4, 2200mAh, 3.7V, Battery charging via USB port on gimbal is not supported. Please use the charger provided for charging batteries.

Usage Time In Theory: 12 Hours (When camera is balanced with gimbal)

Charging Time: 5 hours by the charger provided and the adapter 5V/3A (quick charger is banned). When the indicator on charger give a solid red light, that means batteries are charging. With a solid blue light, batteries are fully charged.

Materials In Main Body: Aluminum Alloys

Weight: 1656g / 3.66lb (not included the battery, shutter release cable, camera, lens and so forth)

Water-Proof Grade: Not Water-proof

Rotatable Range:

• Tilt: 230o(with limitation)
• Roll: 360o (Unlimited)
• Pan: 360o (Unlimited)

Controllable Range:

• Tilt: +175o to -55o
• Roll: 360o (when parallel to the ground, and works in Dutch-Angle shoot mode, it could be automatically rotated 360oin one circle or several circles)
• Pan: 360o (unlimited)

Quick Release Plate: There are two kinds of quick release plate together in one. Bottom mounting plate is compatible with Manfrotto PL501,Upper quick release plate is compatible with ARCA quick release system, which can be removed from the gimbal together with the camera, and fast switch between two popular quick release systems without re-assembling and re-balancing the camera.

COMPATIBILITY LIST

AK4500 Camera Compatibility List (Cable Control)

Sony a6300 / a6400 / a6500 / RX100 IV / a7R / a7SII / a7RII / a7II / a9

Canon 5D Mark III / 5D Mark IV / 80D / 6D / 6D Mark II / EOS R

Nikon Z7 / Z6 / D7500 / D850

Panasonic Lumix GH4 / GH5 / GH5S /

AK4500 Camera Compatibility List(WIFI Control)

Sony a9 / a7 III / a7R III / a7S II / a7R II / a7 II / a7 / a7S /....
