Product Features:

Longest delay time : 00h:00m:01s - 99h:59m:59s 8 channels relay,each channel independently triggered independent delay, do not interfere with each other. 6 kinds of functional modules, each functional module has three sub-modes (no cycle, 2-99 cycle, always cycle). Input optical isolation. Power anti-reverse diode. High Q value SMD electrolytic capacitors. Parameter power-down save

Product Specifications:

1 Operating voltage: DC 12V 2 Operating Current : Standby current (power-saving status) 7MA, Standby current 48MA ,1 relay open 75MA, 2 relays open 102MA, 3 relays open 129MA, 4 relays open 160MA, 4 relays open 160MA,5 relays open 182MA, 6 relays open 207MA, 7 relays open 253MA, 8 relays open 258MA 3 Size: 120x62x20 4 Weight : 128g 5 Relay maximum load capacity: DC 1-110V/5A; AC 85-265V/6A

Typical applications:

1 DC 12V control circuit, "LOAD" may be LED lights, fans, toy car and other DC 12V equipment
