Description:

Input voltage: DC 7- 28V Output voltage: DC 5V Long time maximum output current 3A(12V to 5V) Short time maximum output current 2.4A(12V to 5V) Conversion efficiency: 81-96% Switching frequency: 1.5MHz Output ripple: 40mV (max) Quiescent Current : 0.23mA(input 12V) Load regulation: ?R 0.5% Voltage regulation: ?R 2.5% Operating Temperature: -20 ?a C to +85 ?a C Size: 45 x 22 x 6.5mm (does not include usb connector) Weight : 5.6g

Applications:

DIY Mobile Power Supply, to achieve 5V output for charging Phone,PAD,PSP etc. DIY Car vehicle USB Charger Android IOS Mobile phone charger Smart home / home automation Distributed Power Systems Battery Charger Pre-Regulator for Linear Regulators

Attention :

This is a DC-DC voltage converter module,Must be noted when using: 1 Input voltage can not be greater than the maximum input range 2 Output power can not be greater than the maximum load for a long time 3 Input power must be greater than the output power, because the power consumption of the module itself

The charger can support most mobile phones and PAD charging. But there are still some digital products need identification resistor,If this is the case, please refer to the original charger, increasing identification resistor

Packing list: 1 PCS 3A 5V USB DC DC Converter Step Down Board Estimated delivery timeLsAbout 10 business days.We will use standard shipment for the orders. Normally it may need about 10 days, but sometimes please note: Delivery times are as provided by our carriers and are estimates only. Delays may occur during peak periods, and due to factors outside the carriers control.
