3.5T Hydraulic Tip Trailer | Removable Sides

Custom Built Hydraulic Tip Trailer – 3.5T Braked

Professionally built heavy-duty hydraulic tip trailer, first registered in early 2025 and sold with current WOF and registration.

This trailer is incredibly versatile and can be configured in multiple ways depending on the job. The upper side extensions can be removed independently, the lower sides can be folded down or removed completely, and the trailer can be converted into a flat deck for transporting vehicles, machinery, pallets and building materials.

The trailer was originally built as a standard tipper and the removable upper side extensions were later added to increase capacity. With the extensions fitted it will hold approximately 4.5m³ of mulch, while still allowing it to be quickly converted back to a lower-sided tipper or flat deck configuration.

Ideal for landscapers, builders, contractors, lifestyle blocks, machinery transport, firewood, aggregate, green waste and general hauling.

Dimensions:

• Internal width: 2040mm
• Internal length: 3670mm
• Internal side height: 275mm + removable upper side extensions
• Deck height from ground: 655mm
• Overall length: 5500mm
• Approximate trailer weight: 800kg

Capacity:

• Approximately 4.5m³ mulch capacity with side extensions fitted.

Construction:

• 350 Grade steel construction throughout
• 40x40x3 SHS cross-members
• Sch40 20NB tie rail with heavy-duty tie-down points
• 4mm Corten steel rear bumper
• 3mm aluminium sides
• 21mm Transtex plywood deck and headboard
• Narva lights and markers

Hydraulic Tipping System:

• 12V 8-tonne hydraulic ram
• 600CCA battery
• Solar charging system
• Wireless tipping remote
• Backup remote
• Rubber deck support pads

Wheels & Tyres:

• Heavy-duty 13" wheels
• Spare wheel mounted on drawbar
• 3mm steel mudguards
• Mud flaps fitted

Suspension & Braking:

• 3500kg rated eye-to-eye suspension
• 3500kg rated KNOTT braking system (4-wheel drum brakes)
• 3500kg rated KNOTT coupling
• 65x65x6 SHS axles

Viewing welcome.
