CERWIN VEGA XED6004D SERIES 4 CH 600W

Cerwin Vega 4 Channel Amplifier 500W Max Class D Amp XED Series XED6004D

The Cerwin Vega XED6004D 4 Channel Amplifier is the perfect addition for anyone looking for amazing power in a compact design. The XED6004D features the latest high-efficiency digital Class D topology. This amp offers 500 Watts max in a compact design, giving you all the power you need without wasting space. And to top it all off, the XED6004D features an ambient backlit logo to be the perfect visual accent to your vehicle's audio system.

4 Channel XED Series Amplifier / 600W MAX

Features:

• Latest High-Efficiency Class D Topology
• Compact Size with Ambient backlit logo
• RCA "Pass Thru" output for easy system expansion
• Fully Variable Crossovers (12dB per octave)
• Handles HI and LO level input to 12V
• 2O Stable Stereo and 4O Mono (CH3/4) for 3 Ch mode
• Proprietary Vega Bass Boost EQ Up To 12dB

Specifications:

• Max Power: 500W MAX
• RMS Power @ 2 ohm: 4 x 120W
• RMS Power @ 4 ohm: 4 x 80W
• Type: Class D
• Power Supply: Full PVM
• Power Supply Threshold: 10.0DVC - 16.0DVC
• Idle Current: (0.7A)
• THD 4 (100Hz @4O): 20.0V
• Impedance-Low Input Level: 10 KO
• Impedance-High Input Level:100 KO
• Output Impedance: 2O
• Damping Factor (50Hz @ 4O): >70
• Bandwith (-3dB): 10Hz - 250Hz
• Crossover (-12dB/Oct) Varile High Pass: 35Hz-250Hz
• Crossover (-12dB/Oct) Varile Low Pass: 35Hz-250Hz
• Crossover (-12dB/Oct) Varile Sub-Sonic: N/A
• Fuse Rating ATC (inside): 2x 25A
• Dimensions: 7.1" x 4.7" x 1.8" / 180mm x 120mm x 46.5mm
